SuperCut High Power Fiber Laser Cutting Machine
The SuperCut high power laser cutting systems offers smooth cutting surface, high accuracy, perfect squareness and easy materials handing. SuperCut series lasers utilize a gantry structure with precision dual rack& pinion drives and AC servo motors providing customers with high precision, fast and reliable performance. It has diversified sheet choice for metal processing.
Product Introduction
With advanced laser technology and concept of machine tool design, SuperCut laser cutting machine has updated the basic configuration, including laser source and cutting head, has solved the problems of cutting quality of super-thick stainless steel and aluminium alloy and adhering slag .
Features:
● Bright surface Cutting
Smooth cutting surface, high accuracy, perfect squareness
● Diversified Sheet Choice
Standard cutting mode and SuperCut Mode
● Intelligent Cutting System
Auto-controlling and auto-focusing cutting gas
● Auto-Loading & Unloading System
Functions:
● Max. Power Supply: 8000W
● Thickness of Cutting : ≥30mm
● Cutting Speed: 60m/m for 1mm sheet metal
● High-speed Perforation: diversified high-speed perforation technology
● Back-off Function: back-off to along the original route
● Nozzle Cleaning: auto-nozzle cleaning
● Sheet Metal Nesting and Typesetting
● Auto-Line Tracking: auto calculating angle between sheet metal and machine tool coordinate
● Handheld Unit: Self-invented handheld unit, convenient for technology parameter adjustment
● Cutting gas controlling: Advanced integrated high pressure proportional valve
Professional Configuration
● High Efficient Cutting Head: optimized optics stability to ensure maximum production efficiency
● Professional Controlling System: SIMENS 840D controlling system and configurated driving motor
● Humanization Design: Fully-covered for safety and convenience
SuperCut laser cutting machine is widely used in sheet metal processing, automobile manufacture, gym equipment, smart furniture, home appliance, aeronautical and space, ships and etc.
Tech Parameter
Model | DF 6022 | |
X Stroke | 6096 mm | |
Y Stroke | 2200 mm | |
Z Stroke | 150 mm | |
Positioning Accuracy | ± 0.05 mm | |
Repeatability Accuracy | ± 0.025 mm | |
Positioning Speed | 150 m/min (single) | |
210 m/min (linkage) | ||
Acceleration | 2 G | |
Fiber Laser Source Power | 1 – 2 KW | |
Thickness of Cutting Board MS | ≤ 16 mm | |
Thickness of Cutting Board SS | ≤ 8 mm | |
Exchangeable Worktable | Bearing | 1500kg |
Exchanging Period | 30seconds |
farley Laserlab GF3015 Fiber Laser Cutting Machine adopts gantry-motion structure, linear guide, screw drive, AC servo motor and drives, and vacuum system (both sides), etc. The one-time processing area is 3m*1.5m.Not only that the equipment's design is advanced and reliable, but also that all key components are from both national and international well-known brands. In particular, we use Germany BECKHOFF' company's professional laser CNC system for the electrical control system. This special laser CNC system has advantages of high integration, better control precision and more stable operation, therefore, in addition to the meet the requirement of cutting carbon steel plate, it can also meet the requirement of cutting SS plate, aluminum alloy, copper alloy and other materials.
Specification for GF 3015 Fiber Laser Cutting Machine | ||
| Cutting area(length x width) | 3000mm×1500mm | |
Laser model | Fiber laser IPG-1000W | |
Laser wavelength | 1,070-1,080nm | |
CS cutting thickness | Max. 10mm | |
SS cutting thickness | Max. 5mm | |
Interface | USB,RJ45 | |
| X-axis | Moving speed | 50m/min |
Stroke | 3000mm | |
Position Accuracy | ±0.05mm/m | |
Repeatability Accuracy | 0.05mm | |
| Y-axis | Moving speed | 50m/min |
Stroke | 1500mm | |
Position Accuracy | ±0.05mm/m | |
Repeatability Accuracy | 0.05mm | |
| Z-axis | Stroke | 50mm |
Power supply requirement | 400V/50Hz/30A(36A) | |
Dimension (length×width×height) | 4500mm×2300mm×1500mm | |
ADVANTAGE OF FIBER LASER
1.High speed
* 3-5 times faster than YAG for thin materials
2.Productive
Fiber laser boasts a maximum light conversion efficiency of 3 times than CO2 lasers
3.Low costs
* 25% -30% electricity savings against YAG
* with self-diagnosis system
* short power on/off time
4.Maintenance free
5.Compact structure
6.Easy operation
