Sheet Metal Laser Cutting Machine

Sheet Metal Laser Cutting Machine

Our products were fully recognized in Europe and America’s high-end fiber series products; we have sold and operating many machines around the world since the first fiber cutting machine in 2009, it occupies a big market share within Chinese markets, and outputs of the products has reached multiple countries in global market....

Send InquiryChat Now

Product  Features:

GF3015 is specially for thick plate processing. For example, agricultural machinery, textile machinery, food machinery and construction machinery and other large machinery and equipment manufacturing, usually use high power fiber laser cutting machine for processing.

Environmental-Friendly: Fiber Laser is using Ytterbium as the lighting materials, not necessary to use high-purity helium、nitrogen and CO2 as the consumable materials; High conversion lightning which can up to 30%-40%, the result will be low carbon and more economics.

Ultra-high speed flying cutting: GF3015 machine tool, the dynamic performance of the beam is rising. GF3015 laser cutting machine can cut 0.5mm stainless steel to 100m/min. The high efficient processing guarantee creates higher value for the user.

Cutting expert: Fiber Laser’s wavelength is 1.06μm, 1/10 compare with CO2 Laser, more easy to be absorbed by metal materials, not only higher cutting speed with cutting MS、SUS and SUS, also has fiber Laser’s wavelength is 1.06μm, 1/10 compared to CO2 Laser.



Tech Parameter:

Machine Model

GF3015

Cutting Area(length x width)

3000mm×1500mm

Laser Model

Fiber laser IPG-500W/1000W

Laser Wavelength

1,070-1,080nm

CS Cutting Thickness

Max. 5mm/10mm

SS Cutting Thickness

Max. 3mm/5mm

Interface

USB,RJ45

X-Axis

Moving Speed

50m/min

Stroke

3000mm

Position Accuracy

±0.05mm/m

Repeatability Accuracy

0.05mm

Y-Axis

Moving Speed

50m/min

Stroke

1500mm

Position Accuracy

±0.05mm/m

Repeatability Accuracy

0.05mm

Z-Axis

Stroke

50mm

Power Supply Requirement

400V/50Hz/30A(36A)

Continuous Working Time

24Hours

Machine Weight

Approximate 3000kg

Dimension(length×width×height)

4500mm×2300mm×1500mm



Applicatons:
