Economic CNC Laser Cutting Machine

Economic CNC Laser Cutting Machine

GF3015 series laser cutting machine adopt fiber laser technology, which are made of active optical fiber and semiconductor laser diodes – a combination of two of the most innovative and advanced laser technologies. In order to meet the expectations of a fast pace changing production sphere, HGLaser launched GF series....

Send InquiryChat Now

Product  Features:

-GF3015  series laser cutting machine is specially used for cutting 0.4-16mm carbon steel;0.4-8mm stainless steel, galvanized steel;0.4-8mm aluminum alloy;0.4-6mm brass and various other thin metal.

-Improvement of cutting efficiency by the frog movement,greatly improving the cutting efficiency.

-The double working table is switched at the same time, the transmission is stable, reliable and efficient, the switching time is shortened, and the feeding and feeding time is saved greatly.

-Imported numerical control system and servo motor, integrated self-developed special laser cutting operation system, more flexible operation.

-Gantry type structure, double - driven synchronous compensation technology, stable structure, good rigidity, fast response of laser power setting, in order to keep the quality when cutting the corner.

-Automatically edge searching mode.

-It is widely used in sheet metal cutting, automotive industry, aerospace, pressure vessels, military, metallurgical steel rolling, petroleum, machinery.

 Technical Parameter:

Model

GF3015 Plus

Processing Area

3000mm*1500mm

Machine power

≤27kw

Laser power

500w-2000w

Maximum velocity of movement

100m/min

X/Y axis positioning accuracy

±0.05mm

X/Y axis repeated positioning accuracy

±0.02mm/m

Max loading

800 KG

Transmission

precise pinion and rack,

dual-drive transmitting

Machine dimension

8100mm×2832mm×1750mm

Applicatons:
