Glass Laser Cutting Machine
Picosecond laser glass cutting machine is a high-efficiency, automatic glass cutting machine, using picosecond laser source and RF CO2 laser source to cooperate with glass cutting technology.The glass cutting industry is widely used, for example, glasses manufacturers, lens manufacturing, camera industry, optical lens production, medical industry, lens production in atomized,instruments, smart wearable watch industry, watch glass dial production, automotive industry, automotive rear view mirror glass cutting, cosmetic industry, cosmetic lens cutting.
|
Cutting Light Source |
||
|
1 |
Laser type |
Picosecond pulse laser(the seed source uses the world's mainstream brands such as German Nlight) |
|
2 |
Wave length |
1064nm, beam quality: M2<1.3 |
|
3 |
Pulse length |
<10PS; Pulse frequency:1Hz-1000kHz |
|
4 |
Cooling mode |
Cooling method: water cooling |
|
Segmented light source |
||
|
1 |
Laser type |
CO2 |
|
2 |
Wave length |
1064nm, beam quality: M2<1.3 |
|
3 |
Pulse length |
<30PS; Pulse frequency: 1Hz-1000kHz |
|
4 |
Cooling mode |
Cooling method: water cooling |
Scope of application:
1,reinforced and non-reinforced glass cutting, such as: mobile phone glass cover plate, car glass cover plate, camera glass cover plate.
2,sapphire glass cutting, such as: mobile sapphire cover plate, camera sapphire glass cover plate, sapphire light strip (LED light strip).
3,LCD glass cutting, such as: shaped LCD screen inverted R/U/C Angle, LCD screen cutting.
4,other optical glass cutting, such as: filter cutting, mirror cutting.
5,ordinary glass cutting, such as high borosilicate, quartz glass, white glass, car mirrors, bathroom glass, etc.
6 ,cutting surface screen: single-sided curve (1200-2000), double-sided curve (400-2000) (optional).
Advantages
HGTECH ultra-fast glass laser cutting machine, using self-developed AI control system, high-endcustom picosecond light source, double drive linear motor, marble work surface, cutting oneprocessing, accuracy up to ± 2 microns. Compared with the traditional CNC/ water knifeprocessing has irreplaceable advantages, especially in the shape cutting, fine cutting,non-destructive cutting CNC, is completely incompetent, laser cutting is a non contact cutting, withsimple operation, automatic, no consumables, no pollution, no degree, no edge, low powerconsumption. High efficiency (cutting speed up to 15m/min), and the traditional CNC cutting thereare ring mirror pollution, bit loss, edge collapse, scrap rate is high, slow speed and other defects, and HGTECH glass laser cutting machine to solve all the above problems at one time, greatly saving manufacturing costs for processing manufacturers, improve product profits.
Q: What we can do for you?
A: We are committed to providing you with advanced equipment, technical solutions, and comprehensive service support to help you improve production efficiency, reduce costs, and optimize product quality.
Q: Are you a trade company or manufacturer?
A: We are a manufacturer with independent research and development capabilities and manufacturing capabilities, but we also provide OEM and ODM services.
Q: What is your delivery date?
A: About 30 days after receipt of payment.
